A 1632 eMobility Analyser - Metrel

The A 1632 eMobility Analyser is a special accessory designed for diagnostic testing of Electric Vehicle Supply Equipment (EVSE) together with supported METREL installation testers.

It supports verification of electrical safety and functional testing of Type 1 and/or Type 2 EVSE as well as testing of Mode 2 and Mode 3 electrical vehicle (EV) charging cables and communication monitoring between the charging station and the EV during charging. Fully supported professional station-based and cable-based report creation with MESM software.

more details

Downloads

Request Offer

Features

Functional testing of EVSE via simulation of electrical vehicle’s CP and PP circuits;
Diagnostic testing of EVSE via simulation of errors on CP circuit (output side);
Electrical safety testing of EVSE;
Functional testing of Mode 2 EV cables via simulation of electrical vehicle’s CP and PP circuits;
Diagnostic testing of Mode 2 EV cables via simulation of errors on CP circuit (output side) and mains (input side);
Electrical safety testing of Mode 2 EV cables with installed IC-CPD protection;
Electrical safety testing of Mode 3 EV cables;
Accessible inputs/outputs for connection of safety testers;
Bluetooth communication with Metrel safety testers and Android devices with eMobility app.

Advantages

The combination of A 1632 eMobility Analyser or A 1532 EVSE adapter with Metrel’s installation testers the MI 3155 EurotestXD or MI 3152 EurotestXC offers a complete solution for testing in circuits with a EV RCD or EV RCM 6 mA DC trip-out protection.
It is possible to perform a compete RCD test sequence including the 6 mA DC ramp test and loop impedance (Zs rcd) measurement without tripping 6 mA DC EV RCD or EV RCM. This makes Metrel compliant with standards IEC 62752 (when Mode 2 EV cables are used) and EN 62955 (when Mode 3 cables are used).
