Assembly frame – Assemblex – Rittal

Despite the high level of automation in the switchgear manufacturing process, there are still some situations which call for manual machining. The ergonomically coordinated assembly frames plus storage and transport trolleys help to create optimised working conditions.

The new assembly frames from Rittal, Assemblex, are a revolutionary tool in the switchgear manufacturing process. The health problems associated with posture and comfort issues in the workplace will be part of the past.

The assembly frames of Rittal are available in 3 different configurations with respect horizontal and vertical adjustment, working height and supported load.
more details
Downloads
Request Offer
Features
  • Adjustment range: adjustable from the vertical to the horizontal;
  • Working height: from 0,8 to 1,1 m;
  • Tilt adjustment: 0-80°;
  • Maximum supported load: from 150 kg to 300 kg.

Advantages
  • Simple handling due to four castors including total lock function;
  • Tilt-adjustable and optionally height-adjustable;
  • Ergonomic, effective, time-saving construction;
  • Wire routing;
  • Wire reel holder;
  • Reel track for side insertion of mounting plates.

Industries
  • Panel builders / machine builders.

F.Fonseca is distributor of Rittal in Portugal.
