Portable ultrasonic flowmeter AUF610 - ALIA
The AUF610 series is a portable transit-time ultrasonic flowmeter with clamp-on transducers for non-invasive liquide measurement. Based on microprocessor and programmable flow measurement techniques, the process flow can be accurately measured without interrupting the flow and with low installation costs.
more details
Downloads
Request Offer
Features
Advantages
Industries
F.Fonseca is the representative of ALIA in Portugal.
- 4 line LCD to display flowrate, totalizer signal condition, etc;
- The flowmeter is designed in high accuracy +/- 1.0%;
- Small sized (206*100*35 mm) light-weight (600 g);
- Wide range, velocities (0.01 ~ +/- 32 m/s);
- Ni-MH battery lasts for over 10 hours continuous operation;
- Maximum temperature 160ºC;
- Transducers for pipes size from 15-6000 mm (1/2” - 240”);
- Built-in magnet in transducers, no need for steady tool on metal pipe;
- Data logger which records flowrate, date, total flow, signal condition, and other parameters;
- Response time less than 1 second.
Advantages
- Portable;
- Non-invasive liquid measurement;
- Measuring without interrupting the flow;
- Low installation costs.
Industries
- Chemical and pharmaceutical industry;
- Facility management;
- Food and beverage industry;
- Power plants;
- Water companies.
F.Fonseca is the representative of ALIA in Portugal.
