Industrial Automation
Traffic information collector - TIC102 - Sick
Reliable vehicle classification even over multiple lanes.
The Traffic Information Collector (TIC) from Sick is an integrated traffic measurement system that is based on Sick laser measurement technology, a technology that is used in thousands of traffic applications worldwide. The TIC1xx is especially designed for multilane, free-flow applications such as tolling enforcement and traffic management. Through a highly innovative configuration wizard that includes a live 3D view of the traffic, installation of a multilane gantry is quick and easy. The system autocalibrates in moving traffic and can be accessed remotely for maintenance. A software trigger increases the detection rate and reading accuracy of third-party systems such as ANPR cameras and DSRC antennas, as well as in stop-and-go situations. Additional information such as vehicle speed and dimension are given out over the TCP interface.
The Traffic Information Collector (TIC) from Sick is an integrated traffic measurement system that is based on Sick laser measurement technology, a technology that is used in thousands of traffic applications worldwide. The TIC1xx is especially designed for multilane, free-flow applications such as tolling enforcement and traffic management. Through a highly innovative configuration wizard that includes a live 3D view of the traffic, installation of a multilane gantry is quick and easy. The system autocalibrates in moving traffic and can be accessed remotely for maintenance. A software trigger increases the detection rate and reading accuracy of third-party systems such as ANPR cameras and DSRC antennas, as well as in stop-and-go situations. Additional information such as vehicle speed and dimension are given out over the TCP interface.
more details
Downloads
Request Offer
Features
Advantages
Industries
Ref. A01108166
F.Fonseca is the representative of Sick in Portugal.
- Highly precise vehicle classifications on multiple lanes for free-flowing and blocked traffic flow, even with lane changer;
- Flexible and adaptable classification system;
- Integrated standard classes;
- Reliable operation even at night and in inclement weather;
- Additional information such as speed, vehicle dimensions, triggers for license plate cameras and DSRC antennas.
Advantages
- Automatic calibration: the configuration of multiple lanes takes only minutes;
- The detection of vehicle class, trigger, speed and vehicle dimensions facilitates the use in many application fields;
- For simple integration, the system automatically combines the data of up to 4 lanes and outputs the results on a single interface;
- The vehicle data can be stored directly in the measurement head. This permits independent, temporary measurements to be performed easily;
- No complex installations into the road surface are required;
- The triggering of the TIC102 improves the detection and reading rate of the license plate detection or the DSRC system;
- Long maintenance intervals and fast installation lower the operating costs to a minimum.
Industries
- Vehicle classification for electronic toll collection on multiple lane roads;
- Fast lanes at tollbooths;
- Classic toll station thanks to stop-and-go functionality;
- Traffic management and traffic jam detection through detection of vehicle class, speed and net time interval.
Ref. A01108166
F.Fonseca is the representative of Sick in Portugal.
