SOLID67 – Murrelektronik

SOLID67 are the new compact I/O modules from Murrelektronik. They make installation in the field easier and are very attractive for applications with IO-Link sensors and actuators. They provide eight IO-Link slots directly adjacent to the process and can easily incorporate classic IOs into the system.

Full encapsulation and impressive vibration and shock values (15 and 50 G) prepare the modules for use in harsh industrial environments – within a temperature range of −20 to +70°C. This opens a door to numerous applications. Comprehensive diagnostic options at the module, through the control unit, and through an integrated web server, make troubleshooting a simple exercise.

more details

Downloads

Request Offer

The SOLID67 modules are multi-protocol-compatible. They support ProfiNet and EtherNet/IP. Depending on control concept, a switch is simply placed directly on the module. This reduces the variant diversity. Fewer modules of different types need to be kept on hand.
The slots (pin 4) of the IO-Link master modules are multi-functional. They can be used for IO-Link sensors and actuators, but they can also be configured as classic inputs or outputs. Just a single module is needed to record signals of various types.

Having a width of only 30 millimeters, the slim IO-Link variants of SOLID67 are ideal for use in installations where space is limited. Modules can be connected directly adjacent to the process, and sensors and actuators can be connected using the shortest connection cables.

Features

Compact design: 30mm and 60mm width;
Configurable IO-Link ports;
Compact M12 power cables (L-coded) up to 16A;
Portas I/O M12 A-coded.

Advantages

The SOLID67 modules are multi-protocol-compatible: ProfiNet e Ethernet/IP;
Full encapsulation and impressive vibration and shock resistance;
Ports of the IO-Link master modules are multi-functional;
Comprehensive diagnostic options, through the control unit and integrated web server.
