Industrial and modular touch panel computer TPC-B510 - Advantech

The flexible modularized technology design allows users to change the monitor size or computer CPU performance according to their usage demands.
Advantech's TPC-B510 computing box module, as a member of the Modular Series TPC family, is powered by 8th generation Intel Core processors. With its compact and fanless design, TPC-B510 delivers high performance that not simply meets your demands for a daily-operation control panel, but a genuine Industry 4.0-era-tailored Industrial PC that features bountiful I/Os including four USB 3.1 ports, expansions with M.2 NVME SSD and 5G/Wi-Fi module support for ultra speed data transmission.
more details
Request Offer
With an easy pairing with modular series FPM module, the whole system makes an IP66-grade powerful Panel PC that ranges from 12.1" to 23.8" with up to FHD resolution, adapting to your corporate demands both visually and technically.
  • Modular computing box powered by 8th Gen. Intel® Core™ i3- 8145UE dual-core/i5-8365UE quad-core/i7-8665UE quad-core processor with built-in 8 GB DDR4 SO-DIMM;
  • Dual channel memory slots support up to 32GB in total;
  • Support expansion via full-size mini PCIe and two M.2 slots (NVMe, 5G);
  • Diverse system I/O and isolated digital I/O via iDoor technology;
  • Support fieldbus protocols/GPS/GPRS/Wi-Fi capabilities via iDoor technology;
  • Support TPM2.0 hardware security;
  • Modular front panel modules ranging from 12.1" to 23.8" with P-CAP multi-touch in selection (12.1" features 5-wire resistive touch).
  • With a flexible modular design, they allow users to inter change video interfaces such as FPM 7000 industrial monitors which can be used as an interface of two controllers simultaneously via the PiP (Picture-in-Picture) feature, or expand the signal transmission distance to 100m via iLINK technology;
  • Flexibility with the possibility to use three selectable box modules (Thin-client/Control Panel/Monitor) for different requirements;
  • Easy maintenance in the system simply removing the computing box. No need to unmount the whole unit from cabinet. And simply send out the defect module for repair;
  • Quick customization because touch is designed to quickly respond to different logo requirements. Modularized panel and box allow short L/T of customization and adapt it to standard module;
  • Forward compatibility with easy and economical replacement. Only need to upgrade computing boxes when technology advances.
  • All kind of industries that need to use HMI in the production lines and all the working environment and also machine manufacturers.

F.Fonseca is the representative of Advantech in Portugal.
