In module INP02 - Qbus

Module for connecting external contacts such as regular switches and push buttons, solar/wind detector, motion detector, smoke detectors, …

On the INP02, 2 potencial free contacts and 2 low corrent LEDs (2mAwithout serial resistor) can be connected. The maximum length of the conductor between the INP02 and the potencial free input is 20 meters. The cable type or its section is irrelevant.
more details
Request Offer
The input contacts can be selected and set using the Qbus configuration software:
  • Push button – Button that is open when inactive – only active when pushed shortly (e.g. doorbell);
  • Normal open – contact that is open when inactive;
  • Normal close – contact that is closed when inactive;
  • Switch – when a single pole conventional switch is connected to the input;
  • An INP02 can control 2 outputs, 2 scenes or 2 x 16 scenes (via the sequence function);
  • The two low corrent LEDs that can be connected to INP02 show the status of the mode that has been selected (push button, normal open, normal close, switch);
  • The INP02 is connected on the bus, and gets its power from the bus.
  • Power supply : bus;
  • Characteristic consumption : 2.3VA;
  • Working temp. range : 10°C to 50°C;
  • Storage temp. range : -10°C to 60°C;
  • Maximum humidity : 93%, no moisture condensation;
  • Bus load without LEDs: 6mA, with all LEDs on 8Ma;
  • Max installation altitude : 2.000m.
  • Reduced dimensions;
  • Configurable inputs;
  • LED feedback for output status;
  • Power supply: low voltage.
  • Electrical installers, construction companies, Electrical design offices.
F.Fonseca is the representative of Qbus in Portugal.
