Industrial Automation
Motor feedback systems rotary Hiperface DSL® EKS/EKM36 - SICK
Compact motor feedback system for highly dynamic servo drives.
From a mechanical point of view, the EKS/EKM36 motor feedback system is based on the proven 36 mm design. This design is both compact and rugged, and has been proven many times over in a wide range of applications and surroundings.
In combination with an absolute location indicator system with a resolution of up to 20 Bits per revolution and a maximum of 4,096 revolutions, this design is unique in its class.
From a mechanical point of view, the EKS/EKM36 motor feedback system is based on the proven 36 mm design. This design is both compact and rugged, and has been proven many times over in a wide range of applications and surroundings.
In combination with an absolute location indicator system with a resolution of up to 20 Bits per revolution and a maximum of 4,096 revolutions, this design is unique in its class.
more details
Downloads
Request Offer
Features
Advantages
Industries
F.Fonseca is the representative of SICK in Portugal.
- Motor feedback system with HIPERFACE DSL® interface;
- Compact, robust design with 36 mm diameter;
- Up to 20 bit resolution per revolution and 4,096 revolutions measurable with the multiturn system;
- Facility for connecting an external temperature sensor;
- E²Prom with 8 kbyte of free memory space;
- SIL2-certified (only valid for EKS/EKM36-2...);
- Service life histograma.
Advantages
- Saving all analog components on the controller part through exclusively digital data transmission;
- Enormous cost saving thanks to the separate encoder cable no longer being necessary, data transmitted synchronously to the controller cycle;
- Minimal cabling thanks to integration of the encoder communication into the motor cable;
- Optimization of the controller circuit via automated synchronization with the controller cycle.
Industries
- High-precision servo systems;
- Printing machines;
- Semiconductor industry.
F.Fonseca is the representative of SICK in Portugal.
